SoundCam
First Portable Sound Camera
SoundCam is a portable acoustic camera that images the location of sounds in real time.
It separates and visualizes only desired sounds from surrounding noise, and tracks noise sources that occur momentarily based on a high-speed beamforming algorithm.
With its wide beamforming frequency range and excellent performance in tracking noise sources even at long distances, it is used in a variety of industrial fields from BSR and NVH measurements to leak tests.
All About SoundCam

Noise Inspector
Post-processing analysis software

Supports real-time trigger function

Capable of measuring noise contribution (LTM) over time

Capable of tracking the location of multiple abnormal noises

DAQ integrated, handle type sound camera with display

Real-time analysis possible on site

From the audible to the ultrasonic range

World's first 100FPS
high-speed acoustic imaging
First
Portable Sound Camera
Soundcam is a portable sound camera that images the location of sound in real time.
It separates and visualizes only desired sounds from surrounding noise, and tracks noise sources that occur momentarily based on a high-speed beamforming algorithm.
With its wide beamforming frequency range and excellent performance in tracking noise sources even at long distances, it is used in a variety of industrial fields, from BSR and NVH measurements to leak tests.
Portable
Lightness that can be carried anywhere
SoundCam is light in weight and can be conveniently carried anywhere in the industrial field and measures abnormal noise in real time.



Microphone
64
Multi-channel microphone
SoundCam is equipped with 64 microphone sensors to collect acoustic data from frequencies 10Hz to 100kHz and enables acoustic visualization from 800Hz to 60kHz.


LTM features
Determination of noise contribution during the measurement cycle
It is possible to measure noise contribution over time and provides two visualization modes: Average or Peakhold.

Image output
Do everything with just SoundCam
SoundCam has a tablet PC built into the back, so it can handle everything from measurement to analysis and conversion.
All at once without a separate PC it's possible.

Soundcam measurement
▼
Real-time analysis with rear display
▼
Video and image conversion
Video conversion (*.webm, *.mp4)ㆍAudio conversion (*.wav)ㆍScreen shot (*.png)
Process

4 hours with Lion battery

IP54 Completely waterproof and dustproof design
Compare SoundCam Series

SoundCam
Microphone
64ch
Digital MEMS
Beamforming frequency range
800Hz – 60kHz
Beamforming
Size
34×34×9.5cm
Real-time acoustic imaging speed
100FPS Acoustic information visualization
Weight
3kg
operating temperature
-20ºC to +50ºC
Measuring distance
0.1m~∞

SoundCam Ultra
Microphone
176ch
Digital MEMS
Beamforming frequency range
2kHz – 100kHz
Beamforming
Size
31×16×5.5cm
Weight
1.5kg
Real-time acoustic imaging speed
100FPS Acoustic information visualization
Operating temperature
-20ºC to +50ºC
Measuring distance
0.1m~∞
SoundCam Details
Camera
64ch microphone
LED lights
Power button
Ethernet(LAN) port
USB port
Headphone socket
Power cable port
Battery level indicator
Diameter 340mm

Touch screen
Accessory

Sound Cam

Protective case for airline baggage

Rollei Advanced Tripod

AKG premium headphones
